*Dimensions and weights provided are based on established production standards

 for attachments with pin-on mounts, but variations may occur due to the manufacturing process.

**Dimensions provided are only for the body of the bucket, without the Hydraulic Cylinder

*Dimensions and weights provided are based on established production standards

 for attachments with pin-on mounts, but variations may occur due to the manufacturing process.

Machine
Metric Tons		 Width
/In		 Length
/In		 Height
/In		 Weight
/KG		 Width
/mm		 Length
/mm		 Height
/mm		 Weight
/Lbs
20 42 49 67 963 1,067 1,245 1,702 2,123
45 49 67 993 1,143 1,245 1,702 2,189

Mechanical Clamshell Specifications

GET A QUOTE!

Enter your inquires and info at the form.

We will get to you as soon as possible.

Hydraulic Clamshell Specifications

Features and Benefits

The Clamshell Bucket is a great multi-functional tool to have on the job site. It can be used for material loading and dumping, cleaning up dirt and sand, and even use as a grapple to handle refuse. The wide jaw of the clamshell bucket opens up to 180 degrees and a thick cutting edge closes it tightly. It is a great tool to have during site clearing and clean up.
Applications
  • Loading sand, aggregate and rock
  • Site cleanup and earth moving
  • General purpose use


Machine
Metric Tons		 Width
/In		 Length
/In		 Height
/In		 Weight
/KG		 Width
/mm		 Length
/mm		 Height
/mm		 Weight
/Lbs
Case580 30 29 45 374 762 737 1,143 825
JD310 30 29 48 354 762 737 1,219 780
12 36 48 49 678 914 1,219 1,245 1,495
39 48 49 690 991 1,219 1,245 1,521
20 36 56 55 730 914 1,422 1,397 1,609
42 56 55 1,039 1,067 1,422 1,397 2,291
45 56 55 1,103 1,143 1,422 1,397 2,432
25 42 56 55 1,118 1,067 1,422 1,397 2,465
45 56 55 1,169 1,143 1,422 1,397 2,577
48 56 55 1,280 1,219 1,422 1,397 2,822

  VIDEO


​​OVERVIEW

CLAMSHELL BUCKET
